| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 2 | FUEL SENDER UNIT | 1 | |
| 3 | PACKING PLATE | 2 | |
| 4 | COVER | 1 | |
| 5 | SUCTION PIPE ASSY | 1 | |
| 6 | SEE GP1U77620000 | 2 | |
| 7 | SUCTION PIPE ASSY (CLUSTER PLATE) | 1 | |
| 8 | PACKING PLATE 2 | 1 | |
| 9 | INSERT FUEL TK 1 | 1 | |
| 10 | TUBE SUCTION 2 | 1 | |
| 11 | ELBOW 1FUEL TANK AS | 1 | |
| 12 | NIPPLE | 1 | |
| 13 | . ELBOW AIR VENT | 1 | |
| 14 | NIPPLEFUEL TANK ASS | 1 | |
| 15 | INSERT FUEL TK 2 | 3 | |
| 16 | SCREW10-24 X 1-1/4 | 5 | |
| 17 | SCREW 8-15 X 3/4 | 4 | |
| 18 | SCREW 10-12X5/8 | 5 | |
| 19 | SCREW 10-12X1 1/4 | 14 | |
| 20 | TANK SUPPORT(5433) | 2 | |
| 21 | SCREW tahos_10 X 3/4" | 8 | |
| 22 | CAP FUEL FILLER (WH PURW YMUS(USA) | 1 | |
| 23 | PACKING YMUS(USA) | 1 | |
| 24 | HOSE FUEL FILLER | 1 | |
| 25 | BANDHOSE 70tahos_362.75 | 4 | |
| 26 | AIR VENT ASSY (9204) | 1 | |
| 27 | HOSE FUEL VENT (5/8" X 80") | 1 | |
| 28 | BAND HOSE 32 | 1 | |
| 29 | CLAMP CABLE | 2 | |
| 30 | SCREW tahos_8 X 3/4" (5 per pack) | 2 | |
| 31 | BAND HOSE | 1 | |
| 32 | PAD FUEL TANK (3/8" X 2" X 6") | 20 | |
| 33 | TANK SUPPORT(4793) | 4 | |
| 34 | SOCKET (WHITE) PURW | 1 | |
| 35 | PACKING FUEL FILLER | 1 | |
| 36 | NUT FUEL FILTER | 1 |
