SKI-DOO MX Z X 440 MX Z X 440 10- Frame Harness
10- Frame Harness
№ Наименование Примечание Кол-во
34 Female Terminal 0
35 FEMALE TERMINAL (5.000 per pack) 0
36 Female Terminal Housing, 1 Circuit 1
42 MALE TERMINAL (10.000 per pack) 0
44 Female Terminal 1
46 Female Terminal 0
54 Female Housing, 3 Circuits 1
77 FEMALE TERMINAL (10.000 per pack) 0
110 MALE TERMINAL (10.000 per pack) 0
111 MALE TERMINAL (10.000 per pack) 0
112 Female Terminal 0
127 Male Lock, 3 Circuits 2
135 MALE LOCK 6 CIRCUITS (5.000 per pack) 2
138 Sealing Cap 0
172 FEMALE TERMINAL (10.000 per pack) 0
217 FEMALE TERMINAL (10.000 per pack) 0
221 FEMALE TERMINAL HOUSING 24 CIRCUITS (10.000 per pack) 1
222 LOGEMENT FEMEL.*HOUSING-FEMALE (10.000 per pack) 1
223 FEMALE TERMINAL (25.000 per pack) 0
224 FEMALE TERMINAL (10.000 per pack) 0
225 FEMALE TERMINAL HOUSING 3 CIRCUITS (10.000 per pack) 2
253 Tubing 6 mm  (3.000 per pack) 0
254 Tubing 9 mm (10.000 per pack) 0
255 Tubing 13 mm  (10.000 per pack) 0
257 TUBING 19 MM (10.000 per pack) 0
258 TUBING 10 MM 0
307 MALE TERMINAL HOUSING 1 CIRCUIT 1
308 FEMALE TERMINAL HOUSING 1 CIRCUIT 1
315 Clip 0
317 FEMALE TERMINAL HOUSING 4 CIRCUITS 1
318 BLOC 4 CIRC.FEM*HOUSING-TAB 1
319 MALE TERMINAL 0
320 FEMALE TERMINAL (5.000 per pack) 0
346 CALE 4 CIRC.MAL*WEDGE-4 WAYS M 1
351 CALE 4 CIRC.MAL*WEDGE-4 WAYS M 1
359 MALE HOUSING 2
363 Female Terminal Housing, 2 Circuits 2
366 MALE HOUSING 6 CIRCUITS 3
368 Female Lock, 2 Circuits 2
371 Male Wedge 6 Circuits 3
381 FEMELE LOCK 3
382 FEMALE TERMINAL HOUSING 12 CIRCUITS 1
409 Plug 0
410 Female Housing 24 Circuits 2
411 Retainer Block 2
412 Wire Seal 2
413 LOGEMENT FEMEL.*HOUSING-FEMALE (10.000 per pack) 2
414 LOCK 2
415 Female Terminal 0
420 Tie-Rap 180 mm 0
421 CLIP (5.000 per pack) 0
