| № | Наименование | Примечание | Кол-во |
|---|---|---|---|
| 1 | JOINT EXHAUST 1 | 4 | |
| 2 | BOLT | 4 | |
| 3 | WASHER (5 per pack) | 4 | |
| 4 | GASKET EXHAUST PIPE | 1 | |
| 5 | BAND MUFFLER | 4 | |
| 6 | GASKET EXHAUST PIPE | 4 | |
| 7 | BOLTHEX SKT HEAD | 4 | |
| 8 | BOLTSMALL FLANGE | 8 | |
| 9 | COVER EXHAUST | 1 | |
| 10 | RIVET BLIND (4.7X16.4 YELLOW) | 5 | |
| 11 | EXHAUST COVER ASS'Y | 1 | |
| 12 | BOLT FLANGE | 2 | |
| 13 | NUT SPRING | 2 | |
| 14 | BOLTFLANGE | 2 | |
| 15 | EXHAUST PIPE ASSY 1 | 1 | |
| 16 | COVER 1 | 1 | |
| 17 | RIVET BLIND | 3 | |
| 18 | WASHER PLATE(75J) | 1 | |
| 19 | EXHAUST PIPE ASSY 2 | 1 | |
| 20 | COVER 2 | 1 | |
| 23 | BOLTBUTTON | 2 | |
| 24 | WASHER | 2 | |
| 25 | GASKET MUFFLER | 2 | |
| 26 | BAND SILENCER | 1 | |
| 27 | BAND SILENCER | 1 | |
| 28 | BOLTFLANGE(8AB) | 2 | |
| 29 | SILENCER ASSY | 1 | |
| 30 | COVER 3 | 1 | |
| 33 | DAMPER MUFFLER | 8 | |
| 34 | COLLAR | 4 | |
| 35 | BOLT WITH WASHER | 4 | |
| 36 | PROTECTOR ASSY | 1 | |
| 39 | PLUG | 2 | |
| 40 | PLUG | 2 |
